This gives incredible signal transmission speeds when compared to serial-communication-based devices. However, Gecko G540 is best suited for controllers and control software that sends signals parallelly like Mach3/Mach4 and LinuxCNC. If you want to use GRBL based software like Easel, the best way to go about it is to use an Arduino board flashed with GRBL and couple it with an Arduino DB25 Shield. You can use any controller with the Gecko G540 as long as it can output signals through a 25-pin port. The most popular SmoothStepper is the one from Warp9 Tech Design.
If you do not want to use an ethernet connection, you can use the USB SmoothStepper that connects via the USB port on your computer. If your computer does not have a parallel port, as is the case in most laptops, you could use an ethernet smooth stepper.Įthernet smooth stepper connects to your computer/laptop using an ethernet cable and transmits the control signals from the computer through a DB25 cable that connects to the Geckodrive G540 controller. You can use any control software that supports parallel port operation to control Geckodrive G540. If your control software does not have the charge pump feature, you will have to disable the charge pump feature by flipping the DIP switch on the Gecko G540 controller. If you are using Mach 3/4 control software you will need to enable the charge pump feature in the settings of Mach.
#Gecko g540 power supply serial
The G540 has a native resolution of 10 micro-step or 2000 pulses per revolution, which means you can make really minute movements.įor controlling the Gecko G540 you can hook it up to a computer by connecting the DB25 port on the Gecko and the 25-pin serial port on the computer using a DB25 connector. This is needed to protect the motor by limiting the current going to the connected stepper motor.įor example, if your motor is rated for 2.8 A, you must connect a 2.8K resistor (2.8 x 1000).ĭriver G540 has a trim pot (potentiometer) near each stepper motor port to fine-tune the smoothness of rotation.
#Gecko g540 power supply full
This means you won't be able to extract the full potential of the stepper motor, however, it will function reasonably.įor stepper motors that require currents less than 3.5 A, you will need to connect an appropriate resistor between pin-1 and pin-5.
#Gecko g540 power supply driver
If you are using a stepper motor rated for higher currents than 3.5 A, the driver cannot supply more than 3.5A of current. However, if you are using Gecko G540 you can narrow this margin as it has over current protection and use stepper motors rated for 3.5A or more. The rule of thumb is to select a driver that can supply 1.4 times the current needed by the motors, this is to protect the driver from high currents due to load fluctuation or hard stops. If you want to use a high torque motor you will need a driver that can meet the current demands of the motor. The torque produced by the motor increases with an increase in current. It can supply a maximum current of 3.5 A to each motor that it drives.įor example, a typical NEMA 23 motor with around 180 oz-in of holding torque would require around 2.8 A current. If you keep the current within the rated values, there shouldn't be an issue. The only possible drawback is the heat management, and the G540 is extremely well designed to manage heat. Generally, you want to apply a higher voltage to get high torque even at high RPMs.
More voltage to the stepper motors translates to a faster rapid speed of the axes.
You can use stepper motors with a maximum voltage rating of 50 V.
#Gecko g540 power supply drivers
G540 has four Geckodrive G250X Digital Stepper Drives, one for each stepper motor that it can control.īefore you get confused, know that the G540 motor controller is actually four G250X stepper drivers rolled into one board. In most other stepper drivers, you need to purchase a stepper driver for each motor you need to control. The Gecko G540 can control up to four stepper motors.
